HAULOTTE OPTIMUM 2632E ELECTRIC SCISSOR LIFT
HAULOTTE OPTIMUM 2632E ELECTRIC SCISSOR LIFT
$0.00
KEY FEATURES
- Optimum compactness
- Width of 2 ft 7 in to operate in the most congested areas
- Compact stowed height for easy access through standard doorways
- Exceptional productivity
- Load capacity up to 770 lbs (Compact 2032 E)
- Driveable at full height
- Extended platform
- Long working cycles
- Reliable, easy to maintain.
SPECIFICATIONS
| System Voltage | 24 V | |
|---|---|---|
| Battery Amp Hours | 225 | |
| Operational | ||
| Operating Weight | 4760 lb | 2159.1 kg |
| Hydrauilc System Fluid Capacity | 6.6 gal | 25 L |
| Max Speed | 2.8 mph | 4.5 km/h |
| Tire Size | 15x5x2 | |
| Tire Fill/Type | Solid, non-marking | |
| Platform | ||
| Max Working Height | 32.3 ft in | 9829.8 mm |
| Max Platform Height | 26.3 ft in | 8001 mm |
| Max Platform Weight Capacity | 500 lb | 226.8 kg |
| Platform Length | 7.6 in | 192.5 mm |
| Platform Width | 2.6 in | 65.5 mm |
| Lift Time | 51 sec | |
| Lower Time | 42 sec | |
| Deck Extension | 36 in | 914.4 mm |
| Dimensions | ||
| Overall Length | 7.8 ft in | 2371.3 mm |
| Overall Width | 2.7 ft in | 813.8 mm |
| Height w/ Rails | 7.2 ft in | 2185.4 mm |
| Wheelbase | 6.1 ft in | 1853.2 mm |
| Turning Radius | 7.8 ft in | 2386.6 mm |
| Ground Clearance | 5 in | 127 mm |
