The DMS 240 is a complete core drilling system for a huge variety of drilling applications. It is the most powerful system in the Husqvarna drill motor stand range. The stand is tiltable, and features a convenient carry handle.

• Perfect for drilling reinforced concrete, bricks and other building material for ventilation and plumbing channels, waste evacuation pipes, barriers and road signs.
• The stand can be tilted from 0 to 45 degrees for angle drilling.
• Twin gear carriage allows for accurate alignment that requires minimal adjustment.
• 1-1/4"-7 thread drill connection
• Drill holes up to 10" (153mm) in diameter.
• 24" drilling stroke.
• 2400 watts / 20 amp motor with an two-speed 185/455 rpm gearbox and electric overload protection.
• Mechanical clutch reduces risk of motor damage.
• Base Material Cast aluminum, 4 leveling screws

Benefits.

• Light and compact, it is easy to transport and mount the stand.
• Fast set-up with the integrated vacuum base eliminates anchoring or clamping.
• Equipped with stabilizing guide rollers for accurate drilling as well as cleaner, straighter holes.
• The back support is clamped to the column with a rigid patented locking system, stabilizing operations.
• Adjustment screws on the base plate, carriage and back support can be adjusted with the feed handle.
• The stand has a jacking screw on the top for easy clamping of the stand.
• The stand is equipped with transport wheels.
• Optional vacuum pump available.
