Wacker SM100 Utility Track Loader
Wacker SM100 Utility Track Loader
The compact design and enhanced maneuverability of the SM100 utility track loader allows it to fit into tight spaces where other machine can’t.
In addition to its compact design, the SM100 is comfortable for operators with ergonomic joysticks and reference handles, plush padding, and wide spring-suspension platform for added stability. The strong lift capacity and high hinge pin of the SM100 height allows for easy loading into high sided trucks and dumpsters. The heavy duty undercarriage construction and fast travel speeds means you can do more with less.
MECHANICAL DETAILS
Length without Bucket 84,3 "
Length with Bucket 108,0 "
Track width 9,1 "
Bucket roll back at height max 92 °
Length of Track on Ground 43,0 "
Operating weight 3.300,3 lb
Bucket height at height max. 62,8 "
Angle of departure 25 °
Bucket roll back at ground 25 °
Ground clearance 7,8 "
Buck. dump angle at height max 42 °
Height 58,2 "
Overall width without bucket 35,5 "
Dump reach at max. height 21,9 "
Bucket Hinge Pin Height 85,7 "
ROC at 35% Tip Load 998,7 lb
Fuel Tank capacity 16,9 gal US
