The TD42T TrackDrive access platform offers exceptional all-around performance from such a compact and low weight base, and with a 500lbs safe-working-load, plenty of capacity for tools as well.

Weight-saving design means that site-to-site transportation is more economical and the TD42T is also more efficient, allowing it to work for longer while using less fuel.

TD42T Features

Superb Gradeability

Will climb very steep inclines as high as 45% (24°)

Excellent Traction

Better grip on uneven terrain

Fully Proportional Hydraulic Controls

Simple, reliable & easy to maintain

Weight Saving Design

Lower cost transportation & better fuel economy on site

Non-Marking Tracks

Optional rubber-free tracks available for indoor usage

TD42T Specifications

Working Height (A)

48ft 6in

Working Outreach (C)

25ft

Platform Height (B)

42ft

Machine Width (F)

4ft 7in

Machine Height (D)

6ft 7in

Machine Length (J)

15ft 5in

Working Width (G)

12ft 6in

Travel Speed

1.3mph

Gradeability

45% / 24°

Minimum Weight

4390lbs

Safe Working Load

500lbs

Basket Width

4ft 7in

Basket Depth

2ft 4in

Maximum Slope

21% / 12°

Power

Diesel
