Wacker SW20 Wheeled Skid Loader
Wacker SW20 Wheeled Skid Loader
SW20 Skid Steer Loader: Reach Higher, Lift More
The Wacker Neuson SW20 provides exceptional value by pairing an efficient 56 hp T4F engine with optimized vertical path lift arm design. Operators have the performance they need, with up to 124 in of lift height, excellent reach at full and smooth controls, the SW20 is the ideal machine for loading anything from a tri-axle dump truck to a feed mixer.
MECHANICAL DETAILS
Smooth Edge Bucket
Length without Bucket 106,6 "
Length with Bucket 134,8 "
Wheelbase 43,5 "
Bucket roll back at height max 30 °
Height to top of ROPS 81,5 "
HingePin Hght.(Large Tires) 125,5 "
Height to ROPS (large tires) 83,0 "
Ground Clearance (Large Tire) 9,1 "
Operating weight 6.435,3 lb 2
Bucket height at height max. 96,5 "
Angle of departure 24 °
Bucket roll back at ground 30 °
Bucket-height max. (la.tires) 97,2 "
Ground clearance 7,6 "
Buck. dump angle at height max 42 °
Overall width without bucket 65,9 "
Dump reach at max. height 37,9 "
Bucket Hinge Pin Height 124,0 "
ROC at 35% Tip Load 1.399,9 lb
